Method to create white chat bubbles

Feature Requests Engine Features
1

It’d be super useful to be able to create chat bubbles when making custom chat GUIs.

I find that chat bubbles allow for a spatial awareness so you can see very specifically who is chatting without having to match up names with characters from a distance.

2

You can make this yourself using a BillboardGui and a 9-slice frame. What are you asking for, in specific?

3

Billboard GUI— damn, ninja’d

4

This is a feature request for an official method to make chat bubbles- not a thread asking how. Sure you can do that- but wouldn’t you want an official way to do it and save yourself a ton of work?

@OP, you can do something like this with ChatService’s Chat method
http://wiki.roblox.com/index.php?title=API:Class/Chat/Chat

5

Unfortunately, I haven’t found a way to perfectly mimic the way ROBLOX does their bubbles with billboard GUIs. They scale a bit differently based on distance.

@anon15335870 Those chat bubbles are a bit different than the ones used by ROBLOX. There’s no option for “White” here:

6

Seems a bit redundant, don’t you think? It’s not a lot of work.

7

I know they are, but it’s a work-a-round for now.

8

This CoreScript might be of interest to you. I don’t know if it is in use yet but it is (or will be) the CoreScript that creates BubbleChat.

3 Likes
9

Somehow I completely missed that! Thank you.

10

http://wiki.roblox.com/index.php?title=API:Class/TextService/GetTextSize

For some reason this method is locked and that script uses it. Any ideas?

11

Try this?

http://wiki.roblox.com/index.php?title=API:Class/TextLabel/TextBounds

12

I tried that myself, doesn’t work too great (by itself, that is). There’s cases where it will cut off the text too early using that method.

(Demonstrated here)
http://a.pomf.cat/vtypxr.mp4

I have this here ugly function for it, that’s part of my UI library I use for Heroes’ Legacy.

local utilGui = Instance.new("ScreenGui", playerGui);
utilGui.Name = "GuiUtilHelper";
local textSizeHelper = Instance.new("Frame", utilGui);
textSizeHelper.BackgroundTransparency = 1;
textSizeHelper.Size = UDim2.new(1, 0, 1, 0);
textSizeHelper.Position = UDim2.new(-2, 0, 0, 0);
textSizeHelper.Name = "GetTextSize";

function module:GetTextSize(text, fontSize, fontFamily, bounds)
	bounds = bounds or Vector2.new(1000, 1000);

	local test = Instance.new("TextLabel", textSizeHelper);
	test.Size = UDim2.new(0, bounds.X, 0, bounds.Y);
	test.Text = text;
	test.Font = fontFamily;
	test.FontSize = fontSize;
	test.TextWrapped = true;

	local bounds = test.TextBounds;

	test:Destroy();
	return bounds;
end

I’ve tested it out with the chat core script, simply replace
TextService:GetTextSize(bubbleText.Text, CHAT_BUBBLE_FONT_SIZE_INT, CHAT_BUBBLE_FONT, Vector2.new(BILLBOARD_MAX_WIDTH, BILLBOARD_MAX_HEIGHT))
with
theModule:GetTextSize(bubbleText.Text, CHAT_BUBBLE_FONT_SIZE, CHAT_BUBBLE_FONT, Vector2.new(BILLBOARD_MAX_WIDTH, BILLBOARD_MAX_HEIGHT));

I don’t know why GetTextSize is locked, but yeah. Unfortunately we have to use work-arounds like this.

2 Likes
